| BASIC
INFO |
| Model No. |
ULAP
R14M |
| Product Name |
14
inch windows rugged laptop |
| Operation System |
Windows
11 Pro ( Win 11 Home or Win 10 IOT optional) |
| Dimension |
363.2*287.4*42.1mm |
| Net Weight |
2.9kg
(include battery) |
| Material |
ABS+PC |
| Color |
Black |
| HARDWARE |
| Screen |
14
inch 16:9 FHD IPS display screen, 1920*1080px,1000cd/㎡ (Touch Screen
optional) |
| Processor |
Intel
Core Ultra 7 processor 155H 16C22T, 4.80 GHz; GPU: Intel Arc graphics
(Ultra 5 optional) |
| RAM |
32GB
DDR5 (16GB optional) |
| ROM |
256GB
SSD (M.2 2280 SSD& NVme adaptive,
512GB optional), support TF up to 1TB maximally |
| Camera |
5MP
front camera |
| Battery |
Built-in
11.1V/1300mAh (removable 11.55V/4850mAh li-polymer battery optional) |
| HALL Sensor |
Support |
| Speaker |
4Ω/3W
*2 |
| Keyboard |
US
keyboard with backlight |
| LED Indicator |
Blue |
| TPM |
TPM
2.0 |
| Fingerprint Unlock |
SPI |
| I/O
INTERFACES |
| USB Ports |
*3
(USB3.2*1, USB3.0*1, USB2.0*1) |
| Mini HD-MI V2.0a |
*1 |
| USB Type-C Port |
*1,
support thunderbolt 4 |
| 3.5mm Audio Jack |
*1 |
| Left Expansion Dock |
M.2-2280
PCIE*1, can connect SSD (M.2 E-KEY interface*1 optional) |
| TF Card slot |
*1 |
| RS232 |
*1 |
| Kensington Lock Slot |
*1 |
| RJ45 Port(1000M) |
*2 |
| SIM Slot |
Optional |
| Pogo Pin |
Optional |
| NETWORK
& CONNECTIVITY |
| WiFi |
IEEE802.11a/b/d/e/g/h/i/k/n/r/u/v/w/ac/ax,
support wifi 6 |
| BT |
V5.1(BLE),
transmission distance ~10 meters |
| GNSS |
Built-in
UB M8 module, support GPS/GLONASS |
| 2G/3G/4G/5G Module |
Optional |
| NFC |
Optional
(NXP300) |
| RELIABILITY |
| Waterproof
Grade |
IP65 / MIL-STD-810H |
| Anti-shock
Grade |
1.2 meters |
| Working
Temperature |
-20 °C to 60 °C |
| Storage
Temperature |
-30 °C to 70 °C |
| ACCESSORIES |
| Power Adapter
(19V/3.78A) |
*1 |
| User Manual |
*1 |
| Battery |
Optional |
| Four-charging
dock |
Optional |
