| BASIC
INFO |
| Model No. |
UTAB
R1068 |
| Dimension |
320*230*21.5mm |
| Net Weight |
1233g
(include battery) |
| Material |
ABS+TPU+Metal |
| Operation System |
Android
14 |
| Languages |
Multi-languages |
| Colors |
Black/orange |
| HARDWARE |
| Screen |
10.1
inch Gorilla glass IPS capacitive touch screen, 1920*1200px, 60MHz, 400cd/m2 |
| Processor |
Mediatek
MT8788 Octa Core (A73*2+A53*6), 2.0GHz; GPU:Mali-G72 MP3, 800MHz |
| RAM |
6GB
RAM |
| ROM |
128GB
ROM, support TF card extension up to 1TB maximally |
| Camera |
Double
cameras: 5MP front; 13MP back camera
with LED flashlight |
| Battery |
Built-in
3.8V/20000mah li-polymer battery |
| Sensors |
Acceleration
sensor, light sensor, gravity sensor, gyro sensor, magnetic field sensor |
| Speaker |
8Ω/1W
waterproof speaker *2 |
| Keys |
Volume
+/-, power Button, customs button |
| VESA Holes |
100*100mm |
| NETWORK
& CONNECTIVITY |
| Network Bands |
2G:
GSM 850/900/1800/1900MHz |
| 3G: WCDMA 900/2100MHz |
| 4G: FDD-LTE: B1/B3/B7/B8/B20 or
B2/B4/B5/B12/B17/B28A/B28B ; TDD-LTE:
B40 |
| WIFI |
IEEE
802.11a/b/g/n/ac, support 2.4GHz/5GHz dual band wifi, support wireless AP |
| BT |
V4.2 |
| NFC |
Support, ST21NFCD chipset |
| GNSS |
Support
GPS/A-GPS/GLONASS/Galileo/Beidou |
| I/O
INTERFACES |
| Nano SIM Slot |
*2 |
| USB Type-A 2.0 |
*1 |
| USB Type-C 2.0 |
*1 |
| TF Card Slot |
*1 |
| HD-MI A |
*1 |
| Pogo Pin |
*1 |
| 3.5mm Audio Jack |
*1 |
| OPTIONAL
FUNCTIONS |
| Fingerprint Module |
Optional:
FAP20 optical AGF200 |
| QR Code Scanner |
Optional:
Newland N1 |
| RELIABILITY |
| Waterproof |
IP68/MIL-STD-810H |
| Drop-proof |
1.5m
drop test |
| Temperature range |
Operating:
'20℃-60℃ |
| STANDARD
ACCESSORIES |
| Power Adaptor (9V/2.2A) |
*1 |
| USB Cable |
*1 |
| Hand Strap |
*1 |
| Eject Pin |
*1 |
| User Manual |
*1 |
| Docking
Station |
Optional |
| Shoulder
Strap |
Optional |
| Stylus Pen |
Optional |
