| BASIC INFO |
| Model No. |
UNIWA
NR120 |
| Product Name |
5G
Android PoC Radio |
| Operating system |
Android
13 |
| Dimension |
131*58.5*28mm |
| Weight |
266g
(include battery & belt clip) |
| Material |
PC+10%
fiberglass |
| Color |
Black |
| Languages |
Multi-language |
| HARDWARE |
| Display |
2.4
inch IPS capacitive touch screen, 640*480px |
| Processor |
Unisoc
T158 octa core, 1.6GHz; GPU: Mali-G57
650MHz |
| RAM |
3GB
RAM (4GB RAM optional) |
| ROM |
32GB
ROM (64GB ROM optional), support Micro SD card up to 512GB maximally |
| Camera |
Double
cameras: 5.0MP FF front + 8MP AF rear camera with flashlight |
| Battery |
Removable
4.4V/5000mAh li-polymer battery, support 10W quick charge |
| Speaker |
Front
Φ36/3W stereo loudspeaker, 110dB |
| Buttons |
PTT,
volume +/-, SOS button, group knob, P1/P2, Up/down, Menu, Back, Ai
key, Blue key, Red key |
| LED Indicator |
R/B |
| NETWORK
& CONNECTIVITY |
| Network Bands |
2G:
GSM 850/900/1800/1900MHz |
| 3G: WCDMA 850/900/1700/1900/2100MHz; TDS
B34/39; CDMA BC0/BC1 |
| 4G: FDD-LTE B1/B3/B5/B8/B28a, TDD-LTE:
B34/B38/B39/B40/B41 |
| 5G: N1/5/8/28a/41/78 |
| Wi-Fi |
IEEE
802.11 ac/a/b/g/n, support 2.4GHz/5GHz dual band wifi |
| BT |
Support
BLE 5.0, 3.0+HS, 2.1+EDR |
| NFC |
13.56MHz.
Support ISO18092, ISO14443 A/B, ISO15693, Mifare protocols (ID card reader
optional) |
| GNSS |
Support
GPS/A-GPS/GLONASS/Beidou (Beidou only optional) |
| I/O
INTERFACES |
| Nano SIM Slot |
*1 |
| TF Card Slot |
*1 |
| USB Type-C 2.0 |
*1,
support OTG |
| 3.5mm Audio Jack |
*1 |
| M6 Port |
*1 |
| Charging Contacts |
*2 |
| OTHER
FUNCTIONS |
| PoC function |
Support
zello, smart PTT, pocstar etc. |
| SOS function |
Support |
| IOT-NTN Satellite |
Optional
for OEM order |
| RELIABILITY |
| Waterproof Grade |
IP68 |
| Shockproof Grade |
1.5m |
| Working Temperature |
-20℃~55℃ |
| Storage Temperature |
-30℃~70℃ |
| ACCESSORIES |
| Power Adaptor |
*1 |
| USB cable |
*1 |
| Belt Clip |
*1 |
| User Manual |
*1 |
| Lanyard |
Optional |
| PTT Earphone |
Optional |
| Dock charger |
Optional |
