| BASIC INFO |
| Model No. |
UNIWA
V5N |
| Operating system |
Android
12.0 |
| Dimension |
165*76*16mm |
| Weight |
260g
(including battery) |
| Material |
Plastic |
| Color |
Black+blue |
| Languages |
Multi-language |
| HARDWARE |
| Display |
5.5
inch G+F+F IPS capacitive multi-touch screen, 1440*720px, 320dpi |
| Processor |
Mediatek
MT6765 Helio P35 octa core, up to 2.3GHz; GPU: PowerVR Rogue GE8320 |
| RAM |
4GB/6GB
RAM |
| ROM |
64GB/128GB
ROM, support TF card up to 512GB maximally |
| Camera |
Single
camera: 13MP rear camera with flashlight (8MP front camera optional) |
| Speaker |
1W/2030
box speaker |
| Sensor |
Acceleration
sensor, proximity sensor, light sensor, magnetic field sensor |
| Buttons |
Scan
button*2, power button, volume+/- |
| Battery |
Removable
3.85V/4000mAh li-polymer battery (8000mAh or 3000mAh-EX battery optional) |
| NETWORK
& CONNECTIVITY |
| Network Bands |
2G:
GSM850/900/1800/1900MHz |
| 3G: WCDMA850/900/1700/1900/2100MHz; TDS:B34/B39 |
| 4G: FDD-LTE
B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28A/28B; TDD-LTE: B34/38/39/40/41 |
| WiFi |
IEEE
802.11a/b/g/n/ac, support 2.4GHz/5.0GHz dual-band WiFi |
| BT |
V5.0 |
| GNSS |
Support
GPS/Beidou/GLONASS/Galileo |
| NFC |
Front
NFC, NXP557 chipset, 13.56MHz |
| I/O
INTERFACES |
| Micro SIM Slot |
*2 |
| TF Card Slot |
*1 |
| USB Type-C Port |
*1 |
| 3.5mm Audio jack |
*1 |
| Charging Contacts |
*2 |
| OPTIONAL
FUNCTION |
| 2D Scanning |
Optional:
Zebra SE4710 or Honeywell 5703 |
| RELIABILITY |
| Waterproof |
IP67/MIL-810G |
| Drop-proof |
1.5
meters |
| Temperature range |
Operating: -20℃～60℃
Storage: -40℃～70℃ |
| Humidity range |
Operating: 5％RH~95％RH |
| ACCESSORIES |
| Power Adaptor |
*1 |
| USB Cable |
*1 |
| User manual |
*1 |
| Charging dock |
Optional |
| Scanning handle |
Optional |
