| Basic info |
| Model No. |
Winpad
W107 |
| Style |
Windows
rugged tablet |
| Material |
Plastic |
| Color |
Black |
| Dimension |
290*196*22mm |
| Weight |
1390g
(include battery) |
| Keys |
Volume+/-,
windows key, power key, scanner key x1 |
| Default language |
Multi-languages |
| Screen |
| Screen |
10.1
inch 7H anti-scratch capacitive touch screen, 1920*1200px, 400cd/㎡ |
| Indicator light |
RGB |
| Hardware |
| Operation System |
Windows
10 Home ( Pro and IoT version optional) |
| CPU |
Intel
Core i5-8250U quad core 4M Cache, 3.4GHz (Intel Core i7-8550U optional) |
| GPU |
Intel
UHD Graphics 620 |
| RAM |
DDR4L
8GB RAM (16GB RAM optional) |
| ROM |
Removable
128GB SSD (256GB/512GB optional) |
| TPM |
Built-in
TPM2.0 SLB9665T |
| Small battery |
Build
in 7.4V/860mAh Lithium-ion polymer battery |
| Big battery |
Hot
swap pluggable 7.4V/5000mAh Lithium-ion polymer battery |
| Endurance: 5hrs (default 50% volumn, default
200nit, play 1080P HD video) |
| Power adaptor |
19V/3.42A/65W |
| Sensors |
Gravity
acceleration sensor |
| Fan |
IPX5
fan x1 |
| Network |
| Band |
2G:
GSM: B3/B8 |
| 3G: WCDMA: B1/B8 |
| 4G: LTE FDD: B1/B3/B7/B8/B20/B28A |
| COMMS |
| WIFI |
IEEE802.11a/b/g/n/ac,
dual band wifi (wifi 6 optional) |
| BT |
V4.2
(BLE |
| GNSS |
U-blox
M8Q module, Support GPS/BDS/GLONASS/A-GPS |
| I/O Interfaces |
| SIM card |
x1 |
| TF card |
x1 |
| USB Type-A 3.0 |
x1 |
| USB Ty.0pe-C 3 |
x1 |
| 3.5mm Earphone Jack |
x1 |
| HD-MI 1.4a Mini |
x1 |
| Speaker |
8Ω/0.8W
waterproof speaker x 1 |
| Mic |
Sensitivity:-42db,
Output resistance:2.2kΩ |
| DC-in |
∮5.5mm
Power connector x1 |
| Pogo pin |
12
Pin x1 |
| Ethernet interface |
Optional,
RJ45 board, (10/100M) Ethernet interface x1 |
| Serial port |
Optional,
DB9 board, (RS232)9-line full function x1 |
| USB2.0 |
Optional,
USB2.0 Big USB x1 |
| Multimedia |
| Camera |
Front
camera: 2MP |
| Rear camera: 8.0MP with LED flashlight |
| Other Functions |
| Fingerprint |
SPI
Fingerprint x1 |
| 1D barcode |
Optional,
Honeywell N6551/Optical resolution:
5mil/scan speed: 50 times /s serial port |
| 2D barcode |
Optional,
Honeywell N3680/Optical resolution:5mil/scan speed:50 times /s |
| Reliability |
| Waterproof |
IP65
waterproof |
| Drop-proof |
1.22m
drop test |
| Temperature range |
Operating:
'-20 °C to 60 °C; Storage: '-30 °C to
70 °C |
| Humidity range |
95%
Non-Condensing |
| Certificates |
MIL-STD-810G
etc. |
| Accessories |
| Charger |
x1 |
| Wrist Strap |
x1 |
| Back jacket |
x1 |
| User manual |
x1 |
