| BASIC INFO |
| Model No. |
UNIWA
HS002 |
| Type |
Handheld
Scanner |
| Dimension |
162*71.5*17mm |
| Weight |
255g
(include battery) |
| Operation system |
Android
10.0 |
| Languages |
Multi-languages |
| HARDWARE |
| Screen |
4.0
inch TN capacitive touch screen, 800*480px |
| Processor |
MT6762
Cortex A53 octa core, 2.0GHz; GPU: PowerVR GE8320, 650MHz |
| RAM |
4GB
RAM |
| ROM |
64GB
ROM, support TF card extension up to 128GB maximally |
| Camera |
Double
camera: 2MP front; 8MP AF rear camera with flashlight, anti-shake, macro
shooting |
| Battery |
Removable
3.8V/4500mAh polymer battery |
| Sensors |
Gravity
sensor, light sensor, proximity sensor, vibration motor |
| Keypad |
25
soft and hard rubber buttons, left button x1, right button x1 |
| NETWORK & CONNECTIVITY |
| Network Bands |
2G:
GSM 850/900/1800/1900MHz |
| 3G: WCDMA 850/900/1900/2100MHz |
| 4G: FDD-LTE:B1/B3/B4/B7/B8/B12/B20;
TDD-LTE:B38/39/40/B41 |
| WiFi |
IEEE802.11
ac/b/g/n/ac, support 2.4GHz/5GHz dual band wifi |
| BT |
V5.0+BLE,
Transmission distance 5-10m |
| GNSS |
Support
GPS/GLONASS/Galileo/Beidou |
| I/O INTERFACES |
| Nano SIM slots |
*2 |
| TF Card slot |
*1
(PSAM optional) |
| USB Type-C |
*1,
support OTG function |
| POGO Pin |
*1 |
| OTHER FUNCTIONS |
| 2D Modules |
6602,
Honeywell N5703 N6703 |
| RELIABILITY |
| Waterproof |
IP66 |
| Drop-proof |
6
sides Supports 1.5 meters drops on the marble |
| Rolling test |
500*0.5m
rolling for 6 sides |
| Temperature range |
Operating: -20℃ - 55℃ Storage: -40℃ - 70℃ |
| Humidity range |
5%RH--95%RH
(no condensation) |
| OPTIONAL FUNCTIONS |
| NFC |
Optional |
| 1D |
Optional |
| ACCESSORIES |
| Adapter |
*1 |
| Data cable |
*1 |
| Protective film |
*1 |
| User Manual |
*1 |
| Hand Strap |
Optional |
